Straight male adapter

Straight male adapter

PVDF press fittings in combination with multilayer pipe, a completely corrosion-free system. The synthetic press fittings are made from injection moulded PVDF (Polyvinylidene fluoride)*. PVDF offers the user a unique combination of properties:

  • Highly resistant to pressure and temperature
  • Excellent mechanical strength
  • Extreme flexibility: bending up to 10° is possible
  • Perfectly suited for drinking water and food
  • Highly resistant to chemicals and corrosion
  • Embedding is possible without extra protection

Applications

Potable water
Heating
compressed air
cooling
Sanitary

Solutions

Building Installations
Industry
Utility
Shipbuilding

Assortiment

Articlenumber Product description LxBxH GTIN
17PK-1404 Henco Straight male adapter 14x1/2" 74.5x33x33 05414764019744

Specifications 17PK-1404

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 14 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 38 mm
Working length connection 2 23.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.0887
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-1604 Henco Straight male adapter 16x1/2" 74.5x33x33 05414764019782

Specifications 17PK-1604

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 16 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 38 mm
Working length connection 2 23.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.0911
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-1804 Henco Straight male adapter 18x1/2" 74.5x33x33 05414764019829

Specifications 17PK-1804

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 18 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 38 mm
Working length connection 2 23.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.0925
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-1805 Henco Straight male adapter 18x3/4" 76.5x40x40 05414764019867

Specifications 17PK-1805

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 18 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 39.5 mm
Working length connection 2 23 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.1289
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-2004 Henco Straight male adapter 20x1/2" 74.5x33x33 05414764019904

Specifications 17PK-2004

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 20 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 38 mm
Working length connection 2 23.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.0954
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-2005 Henco Straight male adapter 20x3/4" 76.5x40x40 05414764019942

Specifications 17PK-2005

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 20 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 39.5 mm
Working length connection 2 23 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.1323
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-2605 Henco Straight male adapter 26x3/4" 76.5x40x40 05414764019980

Specifications 17PK-2605

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 26 mm
Contour code connection 1 TH
Length of connection 1 37 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 39.5 mm
Working length connection 2 23 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.1448
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-2606 Henco Straight male adapter 26x1" 80x45.5x45.5 05414764020023

Specifications 17PK-2606

Max. operating pressure 16 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 26 mm
Contour code connection 1 TH
Length of connection 1 37.5 mm
Material connection 2 Brass
Contour code connection 2 TH
Length of connection 2 42.5 mm
Working length connection 2 26 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.1948
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 16
17PK-3206 Henco Straight male adapter 32x1" 92x45.5x45.5 05414764020061

Specifications 17PK-3206

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 32 mm
Contour code connection 1 BE
Length of connection 1 49.5 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 42.5 mm
Working length connection 2 26 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.214
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
17PK-3207 Henco Straight male adapter 32x5/4" 99.5x57x57 05414764020108

Specifications 17PK-3207

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 32 mm
Contour code connection 1 BE
Length of connection 1 52 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 47.5 mm
Working length connection 2 28.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.3024
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
17PK-4006 Henco Straight male adapter 40x1" 84x45.5x45.5 05414764020146

Specifications 17PK-4006

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 40 mm
Contour code connection 1 BE
Length of connection 1 42 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 42 mm
Working length connection 2 25.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.2246
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
17PK-4007 Henco Straight male adapter 40x5/4" 93x57x57 05414764020184

Specifications 17PK-4007

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 40 mm
Contour code connection 1 BE
Length of connection 1 48 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 46 mm
Working length connection 2 27 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.3181
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
17PK-5008 Henco Straight male adapter 50x6/4" 119x68.5x68.5 05414764020221

Specifications 17PK-5008

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 50 mm
Contour code connection 1 BE
Length of connection 1 71 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 49 mm
Working length connection 2 28.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.5006
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
17PK-6310 Henco Straight male adapter 63x2" 142x90x90 05414764020252

Specifications 17PK-6310

Max. operating pressure 10 bar
Material connection 1 Polyvinylidene fluoride (PVDF)
Outer pipe diameter connection 1 63 mm
Contour code connection 1 BE
Length of connection 1 85 mm
Material connection 2 Brass
Contour code connection 2 BE
Length of connection 2 57 mm
Working length connection 2 33.5 mm
Shape Straight
Material sealing Ethylene-propylene diene monomer rubber (EPDM)
With drain valve No
NetWeight 0.9544
DimensionUnitCode MMT
MaximumOperatingPressureLiquid 10
